Main technical parameter
| bubble cover Department branch | The cutting efficiency | Aluminum plastic: 40-200 times/minute Aluminum Aluminum: 120 times/minute |
|---|---|---|
| Maximum forming area | 250 x 250mm | |
| Maximum forming depth | 12mm | |
| Adjustable range of travel | 150~250mm | |
| PVC and PTP wiath and thickness | PVC : 260 x 0.15 - 0.30mm | |
| PTP : 260 x 0.02 - 0.03mm | ||
| Power supply and power | 380V 50HZ, 主电机2.2KW,加热15KW |
| pretend box Department branch | Encasing speed | 80-300 boxes/min | |
|---|---|---|---|
| Box | Quality requirement | 250 - 350g / m² | |
| Dimension range (L x W x H) | ( 70-20 ) x ｛( 35- 85 ) / ( 70 x 120 )｝x ( 14-70 )mm | ||
| Leaflet | Quality requirement | 50 - 70g / m² | |
| Unfolded leaflet specification | ( 80 - 260 ) x ( 90 - 190 ) | ||
| Folded leaflet specification | 1-4 Fold | ||
| Total power | 5.5km | ||
